刀光刀气空间波动效果

空间波动(DistortionMesh)效果实现

Github源码传送门————>SlashDistortion

Bilibili教程传送门————>小祥带你实现刀气空间波动效果

整体思路

现实世界中我们看到的热浪(烧开水，火箭尾焰等)导致的空间波动，物理原理主要是温度升高引起空气折射率的变化，也就是光在空气中传播路径被弯曲了，导致我们透过热浪看后面的物体会出现波动感。游戏中常见的刀光导致的空间波动也是类似的效果，当然我们显然不用和现实一样考虑空气折射率以及光的传播，这时候就该游戏开发糊弄学发力了，实际上我们只需要对渲染结束后的全屏游戏画面进行扰动，也就是偏移采样就能达到类似的效果。所以第一步我们需要生成一张全屏贴图以供采样，这张贴图需要同时包含透明物体和非透明物体，但不包含我们的刀光mesh，所以需要创建自定义Pass控制渲染顺序并进行渲染，设置为全局贴图后续在shader中进行采样。第二步借助扰动贴图偏移screenUV，使用偏移后的坐标对渲染好的全屏贴图进行采样然后绘制刀光mesh即可。

SlashDistortionRendererFeature

private CopyColorRenderPass copyColorRenderPass;
private SlashDistortionRenderPass slashDistortionRenderPass;

public override void Create()
{
    copyColorRenderPass = new CopyColorRenderPass();
    copyColorRenderPass.renderPassEvent = RenderPassEvent.AfterRenderingTransparents;

    slashDistortionRenderPass = new SlashDistortionRenderPass();
    slashDistortionRenderPass.renderPassEvent = RenderPassEvent.AfterRenderingTransparents;
}

public override void AddRenderPasses(ScriptableRenderer renderer, ref RenderingData renderingData)
{
    renderer.EnqueuePass(copyColorRenderPass);
    renderer.EnqueuePass(slashDistortionRenderPass);
}

• CopyColorRenderPass这个pass用来渲染包含所有内容的全屏贴图，所以渲染顺序为设置为在渲染透明物体之后
• SlashDistortionRenderPass这个pass用来渲染刀光mesh，添加到RenderPasses需要放在CopyColorRenderPass之后

CopyColorRenderPass

public class CopyColorRenderPass : ScriptableRenderPass
{
    private Material blitMaterial;

    private class PassData
    {
        public TextureHandle source;
    }

    public CopyColorRenderPass()
    {
        if (GraphicsSettings.TryGetRenderPipelineSettings<UniversalRenderPipelineRuntimeShaders>(out var settings))
        {
            blitMaterial = CoreUtils.CreateEngineMaterial(settings.coreBlitPS);
        }
    }

    public override void RecordRenderGraph(RenderGraph renderGraph, ContextContainer frameData)
    {
        UniversalCameraData cameraData = frameData.Get<UniversalCameraData>();
        UniversalResourceData resourceData = frameData.Get<UniversalResourceData>();

        RenderTextureDescriptor desc = cameraData.cameraTargetDescriptor;
        desc.depthStencilFormat = GraphicsFormat.None;
        desc.msaaSamples = 1;
        desc.graphicsFormat = GraphicsFormat.R16G16B16A16_SFloat;
        TextureHandle tempColor = UniversalRenderer.CreateRenderGraphTexture(renderGraph, desc, "_CameraColorTexture", true);

        using (var builder = renderGraph.AddRasterRenderPass("CopyColor", out PassData passData))
        {
            passData.source = resourceData.activeColorTexture;

            builder.AllowPassCulling(false);
            builder.SetRenderAttachment(tempColor, 0);
            builder.UseTexture(passData.source);

            builder.SetRenderFunc((PassData data, RasterGraphContext context) =>
            {
                Blitter.BlitTexture(context.cmd, data.source, new Vector4(1, 1, 0, 0), blitMaterial, 0);
            });

            builder.SetGlobalTextureAfterPass(tempColor, Shader.PropertyToID("_CameraColorTexture"));
        }
    }
}

• 创建一张贴图Blit当前相机画面(activeColorTexture)到这张贴图
• 数据写到贴图之后通过SetGlobalTextureAfterPass设置为全局贴图供shader使用

SlashDistortionRenderPass

public class SlashDistortionRenderPass : ScriptableRenderPass
{
    private class PassData
    {
        public RendererListHandle rendererListHandle;
    }

    public override void RecordRenderGraph(RenderGraph renderGraph, ContextContainer frameData)
    {
        using (var builder = renderGraph.AddRasterRenderPass<PassData>("Slash Distortion", out var passData))
        {
            UniversalRenderingData renderingData = frameData.Get<UniversalRenderingData>();
            UniversalCameraData cameraData = frameData.Get<UniversalCameraData>();
            UniversalLightData lightData = frameData.Get<UniversalLightData>();
            SortingCriteria sortFlags = cameraData.defaultOpaqueSortFlags;
            RenderQueueRange renderQueueRange = RenderQueueRange.transparent;
            FilteringSettings filterSettings = new FilteringSettings(renderQueueRange, ~0);

            ShaderTagId shaderTagId = new ShaderTagId("SlashDistortion");

            DrawingSettings drawSettings = RenderingUtils.CreateDrawingSettings(shaderTagId, renderingData, cameraData, lightData, sortFlags);

            var rendererListParameters = new RendererListParams(renderingData.cullResults, drawSettings, filterSettings);

            passData.rendererListHandle = renderGraph.CreateRendererList(rendererListParameters);

            UniversalResourceData resourceData = frameData.Get<UniversalResourceData>();
            builder.UseRendererList(passData.rendererListHandle);
            builder.SetRenderAttachment(resourceData.activeColorTexture, 0);
            builder.SetRenderAttachmentDepth(resourceData.activeDepthTexture, AccessFlags.Write);

            builder.SetRenderFunc((PassData data, RasterGraphContext context) =>
            {
                context.cmd.DrawRendererList(data.rendererListHandle);
            });
        }
    }
}

• 创建渲染队列，渲染所有ShaderTagId为SlashDistortion的物体

SlashDistortion

half4 Frag (Varyings input) : SV_Target
{
    float mask = SAMPLE_TEXTURE2D(_MaskTex, sampler_MaskTex, input.uv).a;
    mask = pow(mask, 2.0);

    float2 scrollUV = input.uv + _ScrollSpeed.xy * _Time.y;
    float2 distortion = SAMPLE_TEXTURE2D(_DistortionTex, sampler_DistortionTex, scrollUV);
    distortion = (distortion * 2 - 1) * _DistortionStrength * mask;

    float2 screenUV = GetNormalizedScreenSpaceUV(input.positionCS);
    float2 distortedUV = screenUV + distortion;

    float aberration = smoothstep(_AberrationThreshold, 1.0, length(distortion)) * _AberrationStrength * mask;
    float2 aberrationOffset = distortion * aberration;

    float r = SAMPLE_TEXTURE2D(_CameraColorTexture, sampler_CameraColorTexture, distortedUV + aberrationOffset).r;
    float g = SAMPLE_TEXTURE2D(_CameraColorTexture, sampler_CameraColorTexture, distortedUV).g;
    float b = SAMPLE_TEXTURE2D(_CameraColorTexture, sampler_CameraColorTexture, distortedUV - aberrationOffset).b;

    return half4(r, g, b, mask);
}

• _MaskTex提供透明度值同时作为扰动强度参与扰动计算使得边缘扰动平滑
• _DistortionTex扰动贴图提供偏移量
• scrollUV是给定一个流动速度(_ScrollSpeed)让扰动贴图在UV空间中随时间移动，实现噪声效果流动
• GetNormalizedScreenSpaceUV方法获取当前像素对应屏幕UV，然后加上扰动值对屏幕贴图进行采样
• aberrationOffset在偏移方向再添加一些色偏效果，偏移越多色偏效果越强，分别采样偏移后的RGB通道数值组合成最终像素色值

完结撒花~
