鬼影拖尾效果实现

基于网格烘焙的鬼影拖尾实现

Github源码传送门————>GhostTrail

Bilibili教程传送门————>小祥带你实现鬼影拖尾效果

GhostTrail

public class GhostTrail : MonoBehaviour
{
    public SkinnedMeshRenderer meshRenderer;
    public LayerMask meshLayerMask;
    public float ghostLifeTime;
    public List<Material> ghostMaterials;

    private List<Ghost> ghosts;

    private void Start()
    {
        ghosts = new List<Ghost>();
    }

    private void Update()
    {
        float time = Time.time;
        for (int i = ghosts.Count-1; i >= 0; i--)
        {
            Ghost ghost = ghosts[i];
            if (time - ghost.createTime > ghostLifeTime)
            {
                ghost.RemoveGhost();
                ghosts.RemoveAt(i);
            }
            else
            {
                ghost.UpdateGhost();
            }
        }
    }

    public void CreateGhost()
    {
        Ghost ghost = GhostPool.Get();

        ghost.createTime = Time.time;
        ghost.lifeTime = ghostLifeTime;
        ghost.mesh.Clear();
        meshRenderer.BakeMesh(ghost.mesh);
        ghost.matrix = Matrix4x4.TRS(meshRenderer.transform.position, meshRenderer.transform.rotation, transform.transform.localScale);
        ghost.layer = meshLayerMask.value;
        ghost.materials = ghostMaterials;

        ghosts.Add(ghost);
    }
}

• 鬼影拖尾管理类，负责维护鬼影的生产和销毁
• 创建ghost对象，通过 meshRenderer.BakeMesh 方法烘焙当前SkinnedMeshRenderer的网格数据到Ghost类维护的mesh对象
• 将 TRS矩阵，材质，生命周期 等数据传给ghost对象，Ghost类中去做具体材质更新和渲染
• 在生命周期内的话调用 ghost.UpdateGhost 方法更新鬼影状态，超出生命周期则从维护的鬼影列表移出

Ghost

public class Ghost
{
    public float createTime;
    public float lifeTime;

    public Mesh mesh;
    public Matrix4x4 matrix;
    public int layer;
    public List<Material> materials;

    private MaterialPropertyBlock materialPropertyBlock;

    public Ghost()
    {
        mesh = new Mesh();
        materialPropertyBlock = new MaterialPropertyBlock();
    }

    public void UpdateGhost()
    {
        if(materials.Count < mesh.subMeshCount)
        {
            Debug.LogError("Check your subMesh materials!");
            return;
        }

        float alpha = 1 - Mathf.Clamp01((Time.time - createTime) / lifeTime);
        materialPropertyBlock.SetFloat("_Alpha", alpha);

        for (int subMeshIndex = 0; subMeshIndex < mesh.subMeshCount; subMeshIndex++)
        {
            Graphics.DrawMesh(mesh, matrix, materials[subMeshIndex], layer, null, subMeshIndex, materialPropertyBlock, false, false, false);
        }
    }

    public void RemoveGhost()
    {
        mesh.Clear();
        GhostPool.Return(this);
    }
}

• 一个Ghost类维护一个mesh用于承接烘焙好的mesh数据，一个MPB用于后续mesh更新材质信息
• 在 UpdateGhost 方法中通过替换鬼影材质，更新材质数据来产生自定义的鬼影效果(hologram全息效果，透明度剔除等等)
• 通过 Graphics.DrawMesh 方法根据传入的数据(mesh信息，TRS矩阵，材质，MPB数据，是否生成或接收阴影等)提交绘制mesh的DrawCall进行绘制

Pool

public class Pool<T>
{
    readonly Stack<T> items = new Stack<T>();

    readonly Func<T> itemGenerator;

    public Pool(Func<T> itemGenerator, int initialCapacity)
    {
        this.itemGenerator = itemGenerator;

        for (int i = 0; i < initialCapacity; i++)
        {
            items.Push(itemGenerator());
        }
    }

    [MethodImpl(MethodImplOptions.AggressiveInlining)]
    public T Get() => items.Count > 0 ? items.Pop() : itemGenerator();

    [MethodImpl(MethodImplOptions.AggressiveInlining)]
    public void Return(T item) => items.Push(item);

    public int Count => items.Count;
}

• 使用对象池来降低频繁生成销毁Mesh导致的内存碎片化以及GC压力，这里提供一个轻量通用的泛型对象池
• 使用Stack作为容器，后进先出提高缓存命中率
• Func itemGenerator 泛型委托用于创建泛型类，Get() 方法在栈中没有对象的时候通过这个委托创建一个新对象，后续回收到池子相当于扩容

完结撒花~
